Vertical Summit80 & Summit800
Feature Description and Operation Manual Issue 1.2
121
The following table provides detailed information on the meaning and function of the various
SMDI action codes.
Table SMDI Messages
Action Code
Reason
Purpose
Message Type
SMDI Message
MD 001 0001-
A
Unconditional forward to VM
Put Mail
II
A xxxxx yyyyy
B
Called Station busy
Busy Mail
II
B xxxxx yyyyy
C
Disconnect, connected party
disconnect
II
C xxxxx yyyyy
D
Direct Fwd to VM group
Get Mail
II
D xxxxx yyyyy
E
Error, invalid number
Error
II
E xxxxx yyyyy
H
Two-way Record
record
II
H xxxxx yyyyy
I
DND
DND
II
I xxxxx yyyyy
N
No Answer
No Answer
II
N xxxxx yyyyy
R
Direct ring to VM group
AA
III
R xxxxx yyyyy
Operation
System
The system will interface with the External AA/VM based on database assignments.
Conditions
1. Selection of SMDI or in-band signaling can be configured using Virtual Dip Switch
settings.
2. Only one AA/VM Group (Internal or External) can be defined in the system. Multiple
definitions will cause erroneous system operation.
Programming
Keyset Admin.
STATION GROUPS
Station Group Assignment (PGM 190)
Station Group Attributes (PGM 191)
TABLES
Voice Mail Dialing Table (PGM 234)
DIP SWITCH
Virtual Dip Switch (PGM 453-Button 2)
Web Admin.
STATION GROUP
DATA
Station Group Assignment, Station Group Attributes
TABLES DATA
Voice Mail Dialing Table
MAINTENANCE
Trace Virtual Dip Switch SMDI Setting
