Figure 2.2 System Side View
Number Description
5 Air conditioner - Vertiv™ Liebert® CRV CRD10 or CR019 row based cooling system
1
6 Power Management Cabinet (PMC)
7 IT rack cabinet 3
8 IT rack cabinet 2
9 IT rack cabinet 1
10 Top cable tray
NOTE:
1: The 10kW system uses the Vertiv™ Liebert® CRD10; the 20kW uses the Vertiv Liebert® CR019.
Table 2.2 System Side View
2 Getting Started Proprietary and Confidential ©2024 Vertiv Group Corp. 5
