5.5 Vertiv™ Liebert® RDU-THD Sensor Communication Cable
To connect the Vertiv™ Liebert® RDU-THD sensor:
Refer to the THD Sensor and Emergency Fan Wiring Diagram in the Vertiv™ SmartRow™ 2 Submittal Addendum located on
www.Vertiv.com. The following figures show the routing path.
Figure 5.5 Vertiv™ Liebert® RDU-THD Sensor Communication Cable Connection
Number Description
1 THD Cascade cable connection
Table 5.7 Vertiv™ Liebert® RDU-THD Sensor Communication Cable Connection
