3.2 PMCLayout
Serial Number Description
1 Vertiv™ Liebert® RDU501 Intelligent Monitoring Unit
2 Power Management Unit (PMU)
3 Vertiv™ Liebert® RDU-THD sensor
4 Emergency fan
5 LEDlights and control components
6 HMIdisplay
7 Intelligent locks
Table 3.3 PMC Components
Figure 3.11 PMC Layout
Letter Description Number Description
a PMC10 2N power supply 1 10kVA UPS
b PMC10 single power supply 2 20kVA UPS
c PMC20 2N power supply 3 Maintenance Bypass Cabinet (MBC)
Table 3.4 PMC Layout
