5.9 PDU Communication Cable
To connect the PDU communication cable:
Refer to the Rack PDU Wiring Diagram in the Vertiv™ SmartRow™ 2 Submittal Addendum located on www.Vertiv.com. The
following figure shows the routing path for a single cabinet with two PDU communication cables.
Figure 5.9 PDU Communication Cable Connections
Number Description
1 PDU communication port
2 Top wire trough
3 To any network port of the switch
Table 5.11 PDU Communication Cable Connections
