Wacker Neuson EZ17 - Raising the Seat; Battery Cover

OM EZ17 us 1.0 * ez17w700.fm 7-17
7
Raising the seat
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Open the engine cover.
3. Pull out and hold lock A, and raise the seat.
➥ The seat is unlocked.
Locking the seat
1. Press and hold seat belt buckle A outward.
2. Lower the seat until it engages with an audible click.
➥ The seat is locked if it cannot be raised at the backrest.
3. Close and lock the engine cover.
Battery cover
Opening:
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Loosen screw A.
3. Unhitch cover B on the top side.
Closing:
1. Install the cover and tighten screw A.
A
Fig. 176
A
Fig. 177
Fig. 178
A
B
