Wacker Neuson EZ17 - Rear Tarp (Option)

4-2 OM EZ17 us 1.0 * ez17i400.fm
4
Rear tarp (option)
Installing/removing
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Roll up the rear tarp and secure it with both straps A.
3. Push the rear tarp into the frame or pull it out of the rail under it.
➥ Hooks B must show inward (see figure 43).
Fig. 41
A
Fig. 42
Fig. 43 (shown inside)
B
