OM EZ17 us 1.0 * ez17b510.fm 5-15
5
Rotating the upper carriage
Accident hazard due to possible farther rotation of the upper
carriage in cold operating state!
Further rotation of the upper carriage can cause serious injuries or death.
► The upper carriage can rotate a little bit farther as long as the hydraulic
fluid has not reached its operating temperature yet. Carefully operate
the control lever in cold operating state.
Crushing hazard due to swiveling range of machine!
Persons in the swiveling range of the machine can be seriously injured.
► Ensure that no one is in the swiveling range.
► The upper carriage protrudes beyond the tracks if the machine is
equipped with the extra weight option. Bear in mind the extended width
of the machine.
Damage to machine when working in the immediate vicinity of walls, parts
of buildings or other obstacles.
► Ensure that there are no obstacles in the machine’s swiveling range.
► When the upper carriage is rotated, it protrudes beyond the tracks if
the machine is equipped with the extra weight option. Bear in mind the
extended width of the machine.
Rotating the upper carriage to the left
Push the left-hand control lever to the left.
