OM EZ17 us 1.0 * ez17w700.fm 7-25
7
Live ring (ball bearing)
Crushing hazard when lubricating the ball bearing race!
Crushing hazard causing death or serious injuries!
► Park the machine as shown in Fig. 188.
► Do not rotate the upper carriage.
1. Place the machine on firm, level and horizontal ground.
2. Lower the boom and the stabilizer blade to the ground.
3. Stop the engine, remove the starting key and carry it with you.
4. Apply grease to lubrication point 10 with two strokes of the grease gun.
5. Start the engine, raise the boom and the stabilizer blade.
6. Rotate the upper carriage by 90°.
7. Repeat steps 2 – 6 three times until the upper carriage is back in its
initial position.
8. Rotate the upper carriage several times by 360°.
Keep the lubrication points clean and remove ejected grease.
