Wacker Neuson EZ17 User Manual

OM EZ17 us 1.0 * ez17e300.fm 3-1
3
3Introduction
3.1 Machine overview
Position Designation Position Designation
1 Working light on boom 8 Eye hook for tying down the machine
2 Roof lights (option) 9 Stabilizer blade
3 Lifting eye 10 Travel gear
4 Rotating beacon (option) 11 Handle
5 Engine cover 12 Extra weight (option)
6 Fuel tank filler inlet 13 Towing eye hook
7 Exhaust pipe
Fig. 3
