7-46 OM EZ17 us 1.0 * ez17w710.fm
7
Fuses and relays
• Blown fuses indicate overloading or short circuits. Have the electrical
system checked by a Wacker Neuson service center.
• Only use fuses with the specified load capacity (amperage).
– see chapter “ Relays” on page 9-4
– see chapter “ Fuses” on page 9-4
Battery charge condition
May only be checked by a Wacker Neuson service center.
Charging the battery
May only be checked by a Wacker Neuson service center.
Replacing the battery
The battery is located under the seat.
The battery is “maintenance-free”. However have the battery checked at
regular intervals to ensure that the electrolyte level is between the MIN
and MAX marks.
Checking the battery requires it to be removed and must be performed by
a Wacker Neuson service center.
Always follow the specific battery safety instructions.
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Remove the battery cover (see chapter “Maintenance accesses”).
3. Remove mount A.
4. First remove the black battery lead from the negative terminal (−), then
the red battery lead from the positive terminal (+).
5. Replace the battery.
6. First install the battery lead on the positive terminal (+), then the one on
the negative terminal (-).
7. Install mount A.
8. Install the battery cover.
