5-16 OM EZ17 us 1.0 * ez17b510.fm
5
Rotating the upper carriage to the right
Push the left-hand control lever to the right.
The upper carriage rotates fast if the control lever is pressed farther, and
the upper carriage rotates slowly if the control lever is not pressed as far.
If the upper carriage is supposed to be rotated on a slope, operate the
control lever carefully to avoid fast movements.
Hydraulic swivel unit brake:
The upper carriage’s rotation is sufficiently braked by moving the left-hand
control lever back to initial position. Moving the control lever in the
opposite direction (counteraction) brakes the upper carriage with
maximum hydraulic output.
