Page #213 background image
OM EZ17 us 1.0 * ez17t900.fm 9-11
9
9.13 Weight
Machine weight
Information
The actual machine weight depends on the selected options and must be
read off the type label.
Add the weight of all subsequently installed equipment to the weight of the
machine.
Weight indications can vary by +/ 2%.
Weight of attachments
see “Fields of application and use of attachments” on page 3-5
Standard bucket backhoe bucket 400 mm (16 in)
Excavator forces
According to ISO 6015
Ground clearance/ground pressure
Weight EZ17
EZ17 (with extra
weight)
Transport weight
1
1. Transport weight: basic machine + 10 % fuel capacity.
1594 kg
(3,514 lbs)
1644 kg
(3,625 lbs)
Operating weight
2
2. Service weight: basic machine + full fuel tank + backhoe bucket (400 mm/16 in) + operator (75 kg/165
lbs).
1724 kg
(3,801 lbs)
1774 kg
(3,911 lbs)
EZ17
Max. tearout force
(short stick)
9.1 kN (2,046 lbf)
Max. tearout force
(long stick)
8.1 kN (1,821 lbf)
Max. breakout force
at bucket tooth
18.7 kN (4,204 lbf)
EZ17
Ground clearance 156 mm (6 in)
Ground pressure 0.28 kg/cm² (4 lbs/in²)
Upper carriage rotation
speed
9.4 rpm
