9-2 OM EZ17 us 1.0 * ez17t900.fm
9
The machine has about 17 % less output at altitudes over 800 m (2625 ft)
above see level. However, this does not affect excavator operation
(Yanmar 3TNV80F-SSNS1).
Engine EZ17
Product Yanmar diesel engine
Type 3TNV80F-SSNS1
Design Water-cooled 4 stroke diesel engine
Number of cylinders 3
Displacement 1266 cm
3
(77.3 in
3
)
Nominal bore and
stroke
80 x 84 mm (3.2 x 3.3 in)
Output
12.8 kW at 2200 rpm
(17.2 hp at 2,200 rpm)
Max. torque
65.8 Nm at 1600 rpm
(48.5 ft.lbs. /1,600 rpm)
Max. engine speed
without load
2200 +/− 25 rpm
Idling speed 1300 +/− 25 rpm
Fuel injection system Indirect injection
Starting aid Glow plugs (preheating time 4 seconds)
Fuel tank 22 l (5.8 gal)
Exhaust values
according to
EPA – Tier IV final (for NTE/NTRC cycle)
