OM EZ17 us 1.0 * ez17t900.fm 9-13
9
Legend
Designation Explanation
A Reach from live ring center
B Load hook height
max
Admissible weight or mass value with boom in horizontal
position
With or without the stabilizer blade in traveling direction
With or without the stabilizer blade, 90° to traveling direc-
tion
Lowered stabilizer blade
Raised stabilizer blade
Telescopic travel gear extended
