OM EZ17 us 1.0 * ez17i400.fm 4-21
4
Designation See page
1 Boom swivel pedal
5-26
2 Travel levers
5-14
3 Auxiliary hydraulics pedal
5-26
4 Foot-operated pushbutton switch for hydraulic quickhitch (option)
5-32
5Horn
5-9
6 Control levers
5-12
7 Changeover for hammer/auxiliary hydraulics operation
5-25, 5-26
8 Pressure relief of hydraulic oil reservoir
--
9 Travel speed changeover
5-1
10 Stabilizer-blade lever
5-18
11 Display element
4-22
12 Starter
4-30
13 Seat
4-4
14 Throttle
5-1
15 ISO/SAE changeover (option)
5-17
16 Changeover for stabilizer blade/travel gear extension/retraction
5-18, 5-21
17 Switch panel on control lever base
4-22
18 Upper carriage lock
6-4
19 Not assigned
--
20 Control lever base
4-10
21 Rotary switch for oil flow (AUX II and AUX III) (proportional controls) (option)
5-23
22 Operation of Powertilt (AUX III) or 3rd control circuit (AUX II) proportional controls
(option)
5-30, 5-29
23
24
