DESCRIP TIO N OF THE IN DICATOR, WA RNI NG AND CO NTROL E LEM ENTS
51
W L 3 0
Item Designation Function Symbol
1 Not used No function
2 Heater indicator light Illuminates during preheating
3 Not used No function
4 * Warning light for engine oil pressure Illuminates when engine oil pressure is too low
5 * Warning light for generator Illuminates if the battery is not charged
6 * Warning light for engine temperature Illuminates when engine temperature
7 Indicator light for forward drive Illuminates when gear is set to forward drive
8 Indicator light for reverse drive Illuminates when gear is set to reverse drive
9 Indicator light for crawler gear Illuminates when crawler gear is engaged
