Watts AERCO Edge [ii] User Manual

Edge [ii] Controller Operation Manual
SECTION 6 – ADVANCED SETUP
OMM-139_E • 8/25/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 145 of 196
6.4 Comm & Network
The Comm & Network screen allows you to configure all communication interfaces for a variety
of purpose, such as BAS, onAER or Smart Devices. Each option is described below.
1. Go to: Main Menu → Advanced Setup → Comm & Network.
Figure 6.4: Advanced Setting: Comm & Network
NOTE: You can navigate from one Comm & Network screen to the next in round-robin fashion
using the Page Left and Page Right icons on each screen.
6.4.1 BAS (Building Automation System)
The BAS screen provides communication parameters for both BACnet and Modbus interfaces.
1. Go to: Main Menu → Advanced Setup → Comm & Network → BAS.
2. The default is Off. To enable communication with a BAS, press BAS and choose the
communication protocol:
• BACnet IP
• BACnet MSTP
• Modbus TCP
• Modbus RTU
Figure 6.4.1-1: Comm & Network: BAS Screen, BAS = BACnet IP
