Edge [ii] Controller Operation Manual
SECTION 6 – ADVANCED SETUP
OMM-139_E • 8/25/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 122 of 196
▪ VSP Pump Speed Adjust: Use this parameter to adjust the voltage
signal to achieve the desired pump speed. For example, setting to 110% will
change the signal from 5.0V to 5.5V. (Range: 80 to 120%)
▪ VSP Pump Off Delay: Specify the time delay after the unit stops firing
before shutting the pump off. (Range: 1 to 600 secs.)
▪ VSP Pump Output: The voltage signal sent to the pump (read-only).
▪ VSP Pump Relay: Displays if pump is On or Off
o The following parameters appear only if VSP Pump Mode = Fire Rate:
▪ VSP Piping Configuration: Depending on the configuration of the plant,
choose either 1 Pump Per Blr or 1 Pump Per Plnt.
▪ Boiler Plant Size: Specify how many boilers are in the plant.
(Range: 1 to 16)
▪ Plant VSP Pump min spd: Specify the voltage that will drive the pump
at its minimum speed. (Range 0 to 10.0 V)
▪ Plant VSP Pump max spd: Specify the voltage that will drive the pump
at its maximum speed. (Range 0 to 10.0 V)
▪ Rem Blr VS Pump Add: Specify the address of the boiler to which the
variable speed pump is connected. (Range: 1 to 16)
o The following parameters appear only if VSP Pump Mode = Return Temp:
▪ VSP Pump Decrease: Specify the amount the voltage signal will
increase/decrease for every VSP Pump Decr Time interval.
(Range: 0 to 100%)
▪ VSP Pump Decr Time: Specify the interval at which the VSP Pump
Decrease signal is sent to the pump. (Range: 1 to 600 secs.)
▪ VSP Pump Incr Time: Specify the amount of time for voltage signal to
the pump will reach full speed when Setpoint Limiting or High Temperature
occurs; this overrides VSP Pump Decrease and VSP Pump Decr Time.
When Setpoint Limiting or High Temperature condition ends, the VSP Pump
Decrease and VSP Pump Decr Time resumes. (Range: 1 to 600 secs.)
6.3.2 Cascade Communication
The Cascade Communication screen allows you to modify individual communication
parameters.
NOTES:
• This screen is available only after BST functionality has been enabled (see the Unit Mode
parameter in Section 6.3.1: Cascade Configuration). If the unit is configured as a BST
Manager, its parameters apply to this unit and all BST Client units.
• Some parameters on this screen also appear in EZ Setup (see Section 2). While EZ Setup
is designed to walk you through the full configuring of a unit, this screen allows you modify
individual parameters, as needed.
