Edge [ii] Controller Operation Manual
SECTION 2: EZ SETUP
OMM-139_E • 8/25/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 55 of 196
• Enter the upper and lower limits of the “other” setpoint in the BST Other
Setpt Lo Limit and BST Other Setpt Hi Limit fields.
• Pressing Next takes you to the Select BAS Mode screen; skip to Section 2.4:
Completing the Installation for instructions.
Figure 2.3.2.2.3-11: BST Manager – SH & Other: Other Analog Input Screen
B. If you chose Network, the Select BAS Mode screen appears. Proceed to the next
section, Section 2.4: Completing the Installation, for instructions.
2.4 Completing the Installation
Complete the instructions below to complete the installation. If the unit will communicate with a
BAS, you will select and configure the communicate protocol as well.
1. If the EZ Setup Complete screen appears, skip to Step 7.
2. If the unit will communicate with the site’s BAS (Building Automation System), the Select
BAS Mode screen appears. Press the communication protocol it will use, or else press Off.
Press Next to continue.
Figure 2.4-1: Select BAS Mode Screen
