Edge [ii] Controller Operation Manual
SECTION 1: INTRODUCTION
OMM-139_E • 8/25/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 15 of 196
1.11 Timeout
There is one timeout for both screen sleep mode and password level exit. The timeout is
defined as inactivity on the touchscreen and all front panel buttons.
• The default timeout period is 60 minutes.
• When a timeout occurs, the touchscreen goes into sleep mode and resets the access
level to the default.
• Any activity on the control panel (including a tap on the touchscreen) will activate the
touchscreen and display the Enter Password screen.
•
1.12 The Unit & Plant Status Screens
The Unit Status screen is the touchscreen’s default screen for Benchmark boilers. It is selected
by pressing Unit Status on the Main Menu.
Figure 1.12: Example Unit Status Screen – Status Message Displayed
This screen also appears when the unit powers on (after the splash screen), comes out of sleep
mode and has a successful flame ignition. You can manually navigate away from this screen at
any time, or the system will automatically transition to Ignition screen during the Ignition
sequence.
