SECTION 2: EZ SETUP

The EZ Setup function configures the unit as either a Standalone unit or Client or Manager in a

Boiler Sequencing Technology (BST) Cascade group. If the current unit is the “Manager” of a

BST Cascade group, it sets the operating mode for the “Manager” unit. If it is a “Client” unit in a

BST Cascade group, it sets the operating mode for the “Client” unit.

The EZ Setup screen is accessed by pressing EZ Setup on the Main Menu.

Figure 2.0: Main Menu with EZ Setup Selected

This Section includes the following topics:

2.1: Backing Up and Restoring Settings

2.2: EZ Setup - Standalone

2.2.1 EZ Setup – Standalone – Space Heating Application

2.2.2 EZ Setup – Standalone – Domestic Hot Water Application

2.2.3 EZ Setup – Standalone – Other Application

2.3: EZ Setup - Boiler Sequencing Cascade

2.3.1: EZ Setup – BST Cascade – Client Units

2.3.2: EZ Setup – BST Cascade – Manager Units

2.3.2.1 EZ Setup: BST Manager – Single Application

2.3.2.1.1 EZ Setup: BST Manager – Space Heating Application

2.3.2.1.2 EZ Setup: BST Manager – Domestic Hot Water Application

2.3.2.1.3 EZ Setup: BST Manager – Other Application

2.3.2.2 EZ Setup: BST Manager – Two Applications

2.3.2.2.1 EZ Setup: BST Manager – Space Heating and DHW Applications

2.3.2.2.2 EZ Setup: BST Manager – DHW and Other Applications

2.3.2.2.3 EZ Setup: BST Manager – Space Heating and Other Applications

2.4: EZ Setup - Restoring a Previous Setup

WARNING:

Before starting the instructions in this section for the first time, you must ensure that the unit

has the latest Edge Controller firmware. Complete the instructions in Section 6.2.7: Firmware

Update to obtain and install the latest firmware.
