2.1 Backing Up and Restoring Settings
It is time consuming to setup a unit with correct values for all parameters so it can operate as
efficiently as designed. The Edge Controller provides the option of saving the value of all
parameters configured during setup to either the Controller’s internal memory or to an external
USB device plugged into the side of the Controller. The saved settings can then be restored at
any time, ensuring that the time spent setting up and fine tuning the parameters is not lost.
This is a useful step for two reasons:
• It provides a copy of the original setup, in case it becomes corrupted either through
hardware malfunction or operator error.
• The saved settings can be exported and then uploaded on other units of the same type in
the plant, greatly reducing the time needed to setup other units.
AERCO recommends using this option to guard against the need to recreate a setup from
scratch. Instructions are in the following Sections:
• 6.2.3: Save and Transfer Settings
• Section 2.5: EZ Setup – Restoring a Previous Setup
If a setup was already performed on this (or another similar) unit, and you want to re-load that
setup, see Section 2.5: EZ Setup – Restoring a Previous Setup.
2.2 EZ Setup: Standalone
Complete the instructions below only if the boiler is a standalone unit.
1. Go to: Main Menu → EZ Setup.
2. If the unit was previously setup, the EZ Setup screen appears showing a summary of the
previous setup. Press Abort to retain the previous setup or press Next to continue.
Figure 2.2-1: Standalone: EZ Setup Screen
