Edge [ii] Controller Operation Manual

SECTION 9 – EDGE CONTROLLER VIEWS

OMM-139_E • 8/25/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 186 of 196

Figure 9-2: Edge Controller Rear View

P4 SHELL HARNESS CONNECTOR, 36 PIN

(P/N 63261-TAB)

P2 A/F VALVE HARNESS, 18

(P/N 63218-TAB)

P3 GAS TRAIN HARNESS, 15 PIN

(P/N 63271-TAB)

P1 SENSOR HARNESS, 12

( P/N 63215-TAB)

P6 RIBBON CABLE TO I/O BOARD

40 PIN (P/N 639355-5)

P5 RIBBON CABLE TO I/O BOARD,

30 PIN (P/N 69355-6)

ETHERNET PORT

USB PORT
