www.wegener.com 800009-01 Rev. J 5
iPump 6400 User’s Manual
B Second Decoder Type
(middle slot)
0 - No second decoder
1 - Basic decoder
2 - professional 4:2:0 decoder with analog outputs
3 - professional 4:2:2 decoder with analog outputs
4 - professional 4:2:2 decoder with digital outputs
5 - professional audio output
6 - professional 4:2:0 decoder with analog outputs
and channel 3-4 modulator connector
C Input Type
(bottom slot)
1 - DVB RF Input
2 - ASI Input
D Disk Storage Capacity 1 - 40 Gigabytes
2 - 80 Gigabytes
3 - 120 Gigabytes
4 - 160 Gigabytes
5 - 200 Gigabytes
6 - 240 Gigabytes
E Contact Closure Module
Type
1 - Alarm and contact closure in and out on DB-9
2 - Alarm and contact closure in and out on DB-9,
plus RJ-11 internal modem
F Channel 3-4 Modulator 0 - none
1 - present
G Reserved
HH Conditional Access Type
J Line Cord
(power connector)
1 - U.S.
2 - U.K.
3 - Europe
4 - Australia
KK Other 00 - none
01 - Aux Audio
02 - KenCast FEC
03 - KenCast FEC plus Aux Audio
04 - OSD
05 - OSD plus Aux Audio
06 - OSD plus KenCast FEC
07 - OSD plus KenCast FEC plus Aux Audio
Model Number
Position
Option Name Designator Description
