Installation
14 800009-01 Rev. J www.wegener.com
Table 2.1: iPump 6400 connector details
Alarm
Connector
Details
The DB-9 female alarm connector on the rear panel provides contact closures and openings
during alarm conditions as well as a user relay available for control by
Compel command
(USER CC). Normal conditions represent the contact in normally functioning, powered
operation. Other conditions or commands will reverse the status of the contact from its
normal position.
Pin functions of the DB-9 alarm connector are listed in
Table 2.2. Pin 1 is the common
connection used by both pins 2 and 6. In alarm mode, Pins 1 and 2 are connected together.
When not in alarm mode, Pins 1 and 6 are connected together.
!"Pins 1 and 2 are normally open and are closed during an iPump 6400 alarm.
!"Pins 1 and 6 are normally closed and are open during an iPump 6400 alarm.
!"Pins 3 and 8 on the DB-9 are normally open and may be closed by command from Compel.
!"Pin 5 is the local, user input (0=trigger).
Designation Connector Type Signal Description Additional Information
RF IN
female Type F 950 to 2150 MHz RF carrier
from antenna LNB
A extension cable is shipped already
attached to the RF IN port to allow easier
access for attaching your RF input.
ASI IN
female BNC ASI input signal
Only on
iPump 6400s with the ASI input
option.
AUDIO*
1/8-inch stereo jack Audio output A 1/8-to-RCA adapter is shipped with your
iPump 6400 (one for each active audio
decoder).
AUX AUDIO
1/8-inch stereo jack Audio output Can be "slaved" to decoder 1 or decoder 2
VIDEO*
Mini-DIN4 or BNC Video output A Mini-DIN4-to-RCA adapter is shipped with
your
iPump 6400. Units equipped with the
optional, professional 4:2:2 decoders will
have a female BNC connector.
LAN
female RJ-45 10/100baseT Ethernet
Autosensing; see pinout detail inTable 2.3:
iPump 6400 LAN connector pin
functions
on page 15
CONTACT
CLOSURE/
ALARM
male DB-9 Contact closure/opening in
and out
See pinout detail in
Table 2.2: iPump 6400
Alarm connector pin functions
on
page 15
POWER
Male IEC
receptacle
100-to-120 Vac @60 Hz or
200-to-240 Vac @ 50 Hz
Autoswitching
* See connector details under
Optional Decoder with Digital Output on page 15 if your iPump 6400 is equipped
with a digital output decoder.
