Operation
22 800009-01 Rev. J www.wegener.com
Table 3.1: iPump 6400 front panel LED indicator descriptions
Indicator
Label
Color and State Meaning
CARRIER GREEN constant Receiver is tracking carrier.
GREEN slow blink Receiver is not tracking carrier.
RECORD GREEN constant
iPump 6400 is recording a program.
Off
iPump 6400 is not recording.
DOWNLOAD GREEN constant
iPump 6400 is downloading a file via Compel.
Off
iPump 6400 is not downloading.
LAN GREEN constant
Light network activity over the
iPump 6400’s LAN interface
GREEN slow blink
Heavy network activity over the
iPump 6400’s LAN interface
Off
iPump 6400 observed no packet transfers on the LAN interface during the
last 20 seconds.
COMPEL GREEN constant
iPump 6400 has received a Compel command within the last two minutes.
GREEN fast blink
iPump 6400 has been addressed by Compel within the last five seconds.
GREEN slow blink
iPump 6400 is in tracking mode, Compel is required, but no Compel
command has been received within the last two minutes.
Off
Compel is not required and not received within the last two minutes; or,
iPump 6400 is not in tracking mode.
AUTH GREEN constant
Current transport stream is protected by conditional access (CA) and
iPump
6400
is authorized and descrambling.
GREEN slow blink
Current transport stream is protected by conditional access (CA) but
iPump
6400
is unauthorized.
Off Tracked channel is not scrambled.
WARNING* AMBER constant One or more warning conditions exist. Read warning information from
front-panel LCD.
Off No warning conditions exist.
ALARM* RED constant One or more alarm conditions exist. Read alarm message from LCD.
Off No alarm condition exists.
* When multiple alarm or warning conditions exist, the
iPump 6400 displays those conditions in the order of
importance with the most critical condition displayed first. To scroll through the alarms, use the
right and left arrow
button
