Wegener iPUMP 6400 - LED Indicators; Table 4.1: Ipump 6400 LED Indicator Descriptions

Maintenance and Troubleshooting
64 800009-01 Rev. J www.wegener.com
LED
Indicators
The iPump 6400 displays only one alarm or warning condition at a time on the LCD. When
multiple alarm or warning conditions exist, the
iPump 6400 displays those conditions in the
order of importance with the most critical condition displaying first. After clearing the more
critical item(s), the
iPump 6400 displays any additional alarms or warnings.
Table 4.1: iPump 6400 LED indicator descriptions
Indicator Label Color and State Meaning
CARRIER
GREEN constant Receiver is tracking carrier.
GREEN slow blink Receiver is not tracking carrier.
RECORD
GREEN constant
iPump 6400 is recording a program.
Off
iPump 6400 is not recording.
DOWNLOAD
GREEN constant
iPump 6400 is downloading a file via Compel.
Off
iPump 6400 is not downloading.
LAN
GREEN constant
Light network activity over the
iPump 6400’s LAN
interface
GREEN slow blink
Heavy network activity over the
iPump 6400’s LAN
interface
Off
iPump 6400 observed no packet transfers on the LAN
interface during the last 20 seconds.
COMPEL
GREEN constant
iPump 6400 has received a Compel command within
the last two minutes.
GREEN fast blink
iPump 6400 has been addressed by Compel within the
last five seconds.
GREEN slow blink
iPump 6400 is in tracking mode, Compel is required,
but no Compel command has been received within the
last two minutes.
Off
Compel is not required and not received within the last
two minutes; or, iPump 6400 is not in tracking mode.
AUTH
GREEN constant Current transport stream is protected by conditional
access (CA) and iPump 6400 is authorized and
descrambling.
GREEN slow blink Current transport stream is protected by conditional
access (CA) but
iPump 6400 is unauthorized.
Off Tracked channel is not scrambled.
WARNING
AMBER constant One or more warning conditions exist. Read warning
information from front-panel LCD.
Off No warning conditions exist.
ALARM
RED constant One or more alarm conditions exist. Read alarm
message from LCD.
RED slow blink Boot Fail Mode. All other LEDs are turned off.
Off No alarm condition exists.
