www.wegener.com 800009-01 Rev. J 11
iPump 6400 User’s Manual
CHAPTER 2 INSTALLATION
This chapter provides instructions on unpacking, mounting, and connecting the iPump 6400
as well as connector information including detailed pinouts.
2.1 Unpacking and Inspection
Carefully unpack the unit and its ac power cord and inspect for obvious signs of physical
damage that might have occurred during shipment. Also locate the bag of accessories
including 1/8-to-RCA and SVD-to-RCA adapters. Any damage claims must be reported to
the carrier immediately. Be sure to check the package contents carefully for important
documents and materials.
Note: Please save the packing materials and original shipping containers in case you
must later return the unit for repair. Packing these units in other containers in such a
way that they are damaged will void your warranty.
2.2 Location and Mounting
The iPump 6400 should be mounted in a standard 19-inch equipment rack. After mounting,
maintain a clean, dry environment for the unit.
Precautions
WA RNING
This is a Class A product. In a domestic environment this product may cause
radio interference for which the user may need to take mitigating action.
DANGER
To avoid damage to this and other equipment, or personal injury, the following items should
be strictly observed.
Elevated Operating Ambient
When equipment is installed in a closed or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater than the room ambient temperature.
Therefore, consideration should be given to the ambient air temperature within the rack, and
not just inside the room, when deciding if the maximum recommended ambient operating
temperature (T
MRA
) is being met.
Reduced Air Flow
Equipment should be installed such that airflow required for safe operation of the equipment
is not compromised. To ensure adequate air flow, the
iPump 6400 should be arranged in a
rack with at least one empty rack unit between it and adjacent equipment and with adequate
clearance around both side vents.
Mechanical Loading
Mounting of the equipment in a rack should be such that a hazardous condition is not
produced by uneven loading. This unit is not very heavy, but total rack loading must be
considered. Also, do not rest any unsupported equipment on your
iPump 6400.
