Frequency
Frequency of light output by pulse during executing burst.
Duty Cycle
In per unit pulse cycle, the ratio of light output time to the unit pulse cycle time.
Time
Duration of laser during executing burst.
6.4.4 Follow Control Parameters
Leaping Min. Dis
When the distance is smaller than the value, the system directly traverses to the
start point of the next object without frog leaping and uplifting the cutting head.
Fixed Pos
A fixed height of Z-axis.
You can either click Get Fixed Pos to set current Z-axis machine coordinate as the
fixed position or directly enter the height manually.
Direct Follow Height
If follow height and height for three-segment piercing are less than the value, the
cutting head directly follows to the set height.
If follow height and height for three-segment piercing are greater than the value, the
cutting head follows 1mm and rises to the set height.
6.4.5 Post-task Actions Parameters
Z Up Position
The target position to which the cutting head rises after machining.
XY Axes
Actions of X-axis and Y-axis after machining.
6.4.6 Advanced Function Parameters
Cut Film
Used to solve the problem that film on metal material is melted and stuck to the
cutting head and the sheet during cutting coated metal material.
Methods of film cut include the following:
• Cut single: cut film before machining a single object.
• Cut group: cut film before machining a group of objects and then execute the
same operation to other groups.
