6.3.4 Three-segment Piercing
Three-segment piercing is divided into three segments and used to cut thick
materials.
According to the checked three-segment method, the system executes piercing by
falling the cutting head to the piercing height from the first to the third. See step 3 of
Set Technic Parameters for details.
6.4 General Parameters
This section introduces general parameters that can be set by users.
General parameters include the following:
• Motion control parameters
• Laser device parameters
• Burst parameters
• Follow control parameters
• Post-task actions parameters
• Advanced function parameters
6.4.1 Motion Control Parameters
Frame Speed
Default speed during cutting frame.
Range: [0, Maximum value among the maximum speed values of all axes]mm/min
Default value: 30000
G00 Speed
Default speed during locating.
Range: [0, Minimum value among the maximum speed values of all axes]mm/min
Default value: 30000
Set G00 speed for each axis in G00 Speed(X) and G00 Speed(Y) input boxes which
appear after Set rapid traverse parameters separately is checked.
6.4.2 Laser Device Parameters
Reset Laser
The laser device must be reset to return to normal status after alarms in laser device
are removed.
6.4.3 Burst Parameters
Peak Power
Laser intensity during executing burst.
