If the value is larger than 0, it means that the lead line is closed and the cutting head
will cut at the sealing position.
If the value is smaller than 0, it means that the lead line is unclosed and the cutting
head won’t cut through at the sealing position.
Range: [-500, 500]mm
Seg No.
There may exist N segments (N is a natural number) on the selected object. Each
segment corresponds to a segment number. Setting a segment number is used to
select the corresponding segment on which the lead line is.
-1 refers to taking the whole object as a segment.
Pos Ratio
The ratio of the distance between the start point of the lead line and the start point
of the corresponding segment to the total length of the segment.
Range: [0, 0.999]
5.3 Change the Machining Direction
After drawing an object, the machining direction is counterclockwise by default.
This operation is used to change the default machining direction.
If you need to show the machining direction, do one of the following:
• In toolbar, click .
• In menu bar, click View → Show Direction.
To change the machining direction, do one of the following:
• Change the machining direction of all the objects.
• Change the machining direction of closed objects.
5.3.1 Change the Machining Direction of All Objects
To change the machining direction of all objects, do the following:
1. Select the target objects.
2. Do one of the following:
– In menu bar, click Object → Mach Direction → Reverse Direction.
– In drawing window, right click and select Mach Direction → Reverse.
