– Auto Set
Used to automatically set the selected objects as fill/unfill:
• In sheet cutting configuration, set the selected objects as
fill/unfill according to the nesting relationship automatically.
• In tube cutting configuration, set the selected objects as unfill by
default.
After setting fill/unfill, check fill/unfill attribute by switching to fill mode.
5.2 Set a Lead Line
This operation is used to avoid machining error or damage to the workpiece caused
by long time duration of laser above the start position, so as to improve machining
accuracy.
According to the leading direction, lead line can be divided into the following:
• Lead-in line: consisting of line lead line, arc lead line and hook lead line.
• Lead-out line: consisting of line lead line and arc lead line.
To set a lead line, do the following:
1. Select the target object.
2. To open Set dialog box, do one of the following:
– In drawing toolbar, click .
– In menu bar, click Object → Lead Line → Set.
– In drawing window, right click and select Lead Line → Set.
