Maintenance
0008−1/A2
Winterthur Gas & Diesel Ltd.
1/ 2
General Configuration − Turbocharger on Exhaust Side
DRIVING END
Thrust Bearing Pads
FUEL SIDE
Rail Unit
Clockwise Rotation
Counterclockwise
Rotation
Supply Unit
Turbocharger
Cylinder
Number
Auxiliary
Blower 1
6543
2
7
1 2 3 4 5
WCH03435
Main Bearing
Number
Auxiliary
Blower 2
1
DRAWN FOR
7 CYLINDERS
WCH03435
6 7
89
EXHAUST SIDE
DATA FOR ONE A175 TURBOCHARGER
FREE END
2016
General
