WinGD RT-flex50DF - 8460−1;A1

Maintenance
8460−1/A1
Winterthur Gas & Diesel Ltd.
1/ 5
Removal, Grind, Installation
Tools:
1 Grinding tool 94841 Emery cloth (as necessary
1 Template 94841A 1 Hand drill
1. Preparation 2.......................................................
2. Removal 3.........................................................
3. Sealing Faces − Grind 4.............................................
4. Adjustment 5.......................................................
5. Installation 5.......................................................
5
I
IIIIII
I
IIII
7
WCH02976
1 2
6
Fig. 1
For View II − II
see
Fig. 2, Fig. 4 and
Fig. 7
For View III − III see Fig. 3 and Fig. 7
1 Flange 5 Exhaust valve control unit (VCU)
2 Top housing 6 Flange
3 Screw plug 7 Hydraulic pipe
4 Drain screw
Hydraulic Pipe for Exhaust Valve Drive
2016
