Maintenance
3326−2/A2
Winterthur Gas & Diesel Ltd.
1/ 10
the
Crosshead Pin − Removal and Installation
Tools:
1 Deviation pipe 94117A 2 Manual ratchet 800kg, H4, H5 94016-001
1 Work platform 94142 2 Manual ratchet 1600kg, H2, H3 94016-007
1 Lifting plate 94324 1 Manual ratchet 3200kg, H1 94016-013
2 Lifting rings 94332 2 RUD eye bolt EB 94040-M30
1 Lifting tool 94335 Shackle 94018
1 Wire rope sling 94666 1 Spur−geared chain block (H6) 94017−22
1. Preparation 1.......................................................
2. Crosshead Pin − Removal 2.........................................
3. Guide Shoes − Removal 6...........................................
4. Guide Shoes − Installation 7.........................................
5. Crosshead Pin − Installation 7.......................................
6. Clearance Checks 10................................................
7. Completion 10.......................................................
1. Preparation
WARNING
Injury Hazard: Before you operate the turning gear, make sure that
no personnel are near the flywheel, or in the engine.
1) Read the data in 0012−1 General Guidelines for Lifting Tools.
2) Operate the turning gear to move the applicable crank to BDC.
3) Lock the turning gear to prevent an accidental engine start.
4) Install the work platform (94142), refer to 3301−1.
5) Attach the deviation pipe (94117A) to the column.
6) Remove the inner piston cooling pipe, refer to 3603−1.
7) Prepare the piston, refer to 3303−5 paragraph 1.
8) Remove the top bearing cover, refer to 3303−5 paragraph 2.
Crosshead
2016
