Maintenance
6420−2/A1
Winterthur Gas & Diesel Ltd.
1/ 4
Scavenge Air Receiver − Clean and do Checks
1. General
For the intervals to clean the scavenge air receiver (1, Fig. 1), refer to 0380−1,
Scavenge air receiver. You must also clean and do a check of the scavenge air
receiver after each piston overhaul.
1
II
WCH03363
Fig. 1
I
II
I
For View II − II, see Fig. 3
4
3
2
5
2016
Scavenge Air Receiver (TC at Exhaust Side)
