WinGD RT-flex50DF - Standard Tools

Maintenance
9403−5/A1
Winterthur Gas & Diesel Ltd.
3/45
94013 1 Torque spanner
(Range of adjustment 50−225 Nm)
WCH02642
94014 1 Torque spanner
(Range of adjustment 8−40 Nm)
013.558/05
94015 1 Torque spanner
(Range of adjustment 140−620 Nm)
94016−001
94016−007
94016−013
94016−017
94016A−001
2
2
2
2
2
Manual ratchets
WLL 800 kg, 2,5m stroke
Manual ratchets
WLL 1600 kg 2,5m stroke
Manual ratchets
WLL 3200 kg, 2,5m stroke
Manual ratchets
WLL 6300 kg, 3,5m stroke
Manual ratchets
WLL 250 kg, 2,5m stroke
012.233/04
94017−021
94017−022
1
1
Spur-geared chain block
WLL 2000 kg, 4m stroke
Spur-geared chain block
WLL 2000 kg, 5m stroke
016.621/08
94018−003
94018−006
2
2
Spur-geared chain blocks
WLL 1500 kg, 3m stroke
Spur-geared chain blocks
WLL 3000 kg, 5m stroke
WCH02297
2020
Standard Tools
