Maintenance3425−1/A1
Winterthur Gas & Diesel Ltd.
4/ 9
2.3 Service Life − Calculate
Use the formula below to calculate the rate of wear of a piston ring:
WR =
(D1−D2) x 1000
T2−T1
Where:
D WR = Rate of Wear (mm/1000 hrs)
D T2 = Time (hrs)
D T1 = First recorded operation hours (hrs)
D D1 = First recorded thickness of the chrome-ceramic layer (mm)
D D2 = Second recorded thickness of the chrome-ceramic layer (mm).
See Table 1 for examples of results.
Table 1: Rate of Wear − Examples
D1
D2 T1 T2 WR
0.382 0.367 0 (new) 1500 0.01
0.351 0.340 3500 5000 0.0073
Use the formula below to calculate the remaining piston ring service life:
LT =
(D2−Dmin) x 1000
WR
Where:
D LT = Remaining in-service time (hrs)
D D2 = second recorded thickness of chrome-ceramic layer (mm)
D Dmin = Minimum thickness of the chrome-ceramic layer (mm) (see paragraph
2.2)
D WR = Calculated rate of wear (mm/1000 hrs)
Table 2: Example for Remaining Service Life
D1
D2 Dmin T1 T2 WR LT
0.382 0.367 0.05 0 (new) 1500 0.01 31700
0.351 0.340 0.05 3500 5000 0.007333 39545
2016
Piston Rings and Grooves − Rate of Wear Three Piston Rings
