Maintenance
0330−1/A1
Winterthur Gas & Diesel Ltd.
3/ 25
Crankshaft and Thrust Bearing
Group
Key No.
Description Measured
Direction
Nominal
Dimension
(mm)
(usual, new)
Maximum Clearance,
Dimension
(mm)
(because of worn
components)
1203
1224
Thrust Bearing
Thrust bearing pad thickness
−0.5
− 0.6
67
1 Thrust bearing clearance axial (total) 0.8 to 1.3 2.5
2 Thrust bearing pad, lateral clearance total 6
Clearance Table
