Maintenance
0330−1/A1
Winterthur Gas & Diesel Ltd.
9/ 25
Cylinder Liner
Group
Key No.
Description Measured
Direction
Nominal
Dimension
(mm)
(usual, new)
Maximum Clearance,
Dimension
(mm)
(because of worn
components)
2124 Water guide jacket on cylinder
cover
Water guide jacket Ø
760
+ 0.3
+ 0.1
1 Clearance total 0.40−0.80
Water guide jacket Ø
750
+ 1.10
+ 0.9
2 Clearance total 1.20−1.60
2124 Water guide jacket on cylinder
liner
Water guide jacket Ø
750
− 0.20
− 0.40
3 Clearance total 0.30−0.50
Water guide jacket Ø
695
+ 0.30
+ 0.1
4 Clearance total 0.30−0.70
2124 Cylinder liner
*5 Cylinder liner bore radial 500 503.50
* Make sure that you measure at the correct point.
2016
Clearance Table
