Maintenance
0330−1/A1
Winterthur Gas & Diesel Ltd.
13/ 25
Exhaust Valve
Group
Key No.
Description Measured
Direction
Nominal
Dimension
(mm)
(usual, new)
Maximum Clearance,
Dimension
(mm)
(because of worn
components)
2751 Valve spindle
1 Spindle outer ∅
55
− 0.14
− 0.17
54.40
2751 Guide bush
*2 Bore inner ∅
55
+ 0.03
0
55.35
*3 Bore inner ∅
55
+ 0.03
0
56.20
* Make sure that you measure at the correct points.
2016
Clearance Table
