Maintenance
0330−1/A1
Winterthur Gas & Diesel Ltd.
17/ 25
Piston Cooling and Crosshead Lubrication
Group
Key No.
Description Measured
Direction
Nominal
Dimension
(mm)
(usual, new)
Maximum Clearance,
Dimension
(mm)
(because of worn
components)
3603 Piston cooling and crosshead
lubrication
Sleeve inner ∅
56
+ 0.15
+ 0.12
Sleeve length
115
− 0.08
− 0.10
1 Radial clearance total 0.30−0.39 0.42
2 Clearance vertical 0.08−0.20 0.25
Inside (telescopic) pipe outer ∅
56
− 0.18
− 0.24
2016
Clearance Table
