Maintenance9403−5/A1
Winterthur Gas & Diesel Ltd.
6/45
94101
94101A
1
1
Inside micrometer
(Measuring range 50−1000 mm)
with case
Inside micrometer
(Measuring range 50−1010 mm)
with case
WCH02629
94110 1 Thrust device
for removal and fitting of
main baring cover
X = 590 mm
018.664/09
X
94114B 2 Double pre-tensioning jacks
for elastic studs to main bearing
X = 222 mm
018.664/09
X
94116A 1 Transportation tool
with 2 head screws M6x25
for removal and fitting of
main bearing shell
X = 210 mm
(WLL 50 kg)
018.662/09
X
94116B 1 Lifting lug
for removal and fitting of
main bearing cover
X = 72 mm
018.662/09
X
94116C 1 Trolley
for removal and fitting of
main bearing cover
X = 298 mm
(WLL 500 kg)
WCH02582
2020
Standard Tools
