Maintenance0360−1/A1
Winterthur Gas & Diesel Ltd.
2/ 3
Group Component Design kg
3
3103 Balance weight on crankshaft 307
3122 Flywheel light
heavy
1530−2030
8000
3140 Axial detuner Two parts 408
3303 Connecting rod 1399
3306 Connecting rod shaft 1426
Bottom bearing half for bottom end
bearing with elastic bolts
137
3310 Bottom bearing shell half for bottom
end bearing
Top bearing shell half for bottom end
bearing
Bearing shell crank pin
13.5
20
38
3312 Bearing cover crosshead for top end
bearing
148
3315 Bearing shell crosshead for top end
bearing
43
3326 Crosshead with guide shoes
Crosshead pin
Guide shoe (Free End side)
Guide shoe (Driving End side)
1440
1040
188
184
3403 Piston two-part, with piston rod and
piston rod gland
Piston head
Piston skirt
Piston rod
Spray plate with oil pipe
881
204
39
571
41.5
3603 Inside (telescopic) pipe to piston
cooling and crosshead lubrication
18.9
4
4106 Crankshaft gear wheel 1-part
2-part
375
579
4120 Intermediate wheel with bearing pins
and bearings for supply unit
Bearing pair for intermediate wheel
315
50.4
4325 Starting air shut-off valve 207
2016
Individual Components per Piece in kg
