Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
Page 162/190 © Woodward
Number Content (words) Unit Comment
3964 MOD bus
54 55 27 (54, 55) Alarm message 4
discrete inputs
Bit 15 = 1 \
Bit 14 = 1 /
Terminal 68
0000H = no
Bit 13 = 1 \
Bit 12 = 1 /
Terminal 67
malfunctions are present
Bit 11 = 1 \
Bit 10 = 1 /
Terminal 66
Bit 9 = 1 \
Bit 8 = 1 /
Terminal 65
Bit 7 = 1 \
Bit 6 = 1 /
Terminal 64
Bit 5 = 1 \
Bit 4 = 1 /
Terminal 63
Bit 3 = 1 \
Bit 2 = 1 /
Terminal 62
Bit 1 = 1 \
Bit 0 = 1 /
Terminal 61
56 57 28 (56, 57) Alarm message 5
discrete inputs
Bit 15 = 1 \
Bit 14 = 1 /
Internal
0000H = no
Bit 13 = 1 \
Bit 12 = 1 /
Internal
malfunctions are present
Bit 11 = 1 \
Bit 10 = 1 /
Terminal 74
Bit 9 = 1 \
Bit 8 = 1 /
Terminal 73
Bit 7 = 1 \
Bit 6 = 1 /
Terminal 72
Bit 5 = 1 \
Bit 4 = 1 /
Terminal 71
Bit 3 = 1 \
Bit 2 = 1 /
Terminal 70
Bit 1 = 1 \
Bit 0 = 1 /
Terminal 69
58 59 29 (58, 59) Malfunction message 6 Bit 15 = 1
Internal
Internal fault Bit 14 = 1
Internal
Bit 13 = 1
Internal
0000H = no Bit 12 = 1
Internal
malfunctions are present Bit 11 = 1
Range alarm analog input 4
Bit 10 = 1
Range alarm analog input 3
Bit 9 = 1
Range alarm analog input 2
Bit 8 = 1
Range alarm analog input 1
Bit 7 = 1 \
Bit 6 = 1 /
MCB synchronization time alarm
Bit 5 = 1 \
Bit 4 = 1 /
Shutoff malfunction
Bit 3 = 1 \
Bit 2 = 1 /
Sprinkler operation
Bit 1 = 1 \
Bit 0 = 1 /
Serial interface Y1 to Y5
