Number Content (words) Unit Comment
3964 MOD bus
60 61 30 (60, 61) Malfunction message 7
Internal fault
Bit 15 = 1 \
Bit 14 = 1 /
Internal
0000H = no
Bit 13 = 1 \
Bit 12 = 1 /
Internal
malfunctions are present
Bit 11 = 1 \
Bit 10 = 1 /
Internal
Bit 9 = 1 \
Bit 8 = 1 /
Internal
Bit 7 = 1 \
Bit 6 = 1 /
Internal
Bit 5 = 1 \
Bit 4 = 1 /
Internal
Bit 3 = 1 \
Bit 2 = 1 /
Internal
Bit 1 = 1 \
Bit 0 = 1 /
Internal
62 63 31 (62, 63) Operating mode Bit 15 = 1 \
Bit 14 = 1 /
Terminal 6 set
Bit 13 = 1 \
Bit 12 = 1 /
Internal
Bit 11 = 1 \
Bit 10 = 1 /
Operating mode TEST
Bit 9 = 1 \
Bit 8 = 1 /
Operating mode MANUAL
Bit 7 = 1 \
Bit 6 = 1 /
Automatic 2
Bit 5 = 1 \
Bit 4 = 1 /
Automatic 1
Bit 3 = 1 \
Bit 2 = 1 /
Operating mode AUTOMATIC
Bit 1 = 1 \
Bit 0 = 1 /
Operating mode STOP
64 65 32 (64, 65) Alarm class Bit 15 = 1 \
Bit 14 = 1 /
Internal
0000H = no alarm
Bit 13 = 1 \
Bit 12 = 1 /
Internal
before
Bit 11 = 1 \
Bit 10 = 1 /
Internal
Bit 9 = 1 \
Bit 8 = 1 /
Internal
Bit 7 = 1 \
Bit 6 = 1 /
Internal
Bit 5 = 1 \
Bit 4 = 1 /
Alarm class 3
Bit 3 = 1 \
Bit 2 = 1 /
Alarm class 2
Bit 1 = 1 \
Bit 0 = 1 /
Alarm class 1
66 67 33 (66, 67) Generator active energy kWh
High Word
68 69 34 (68, 69)
Low Word
