Meaning of the number 69 of the telegram " Currently active display message":
Number Meaning
0 GCB synchronization
1 MCB synchronization
2 GCB dead bus start
3 MCB dead bus start
4 Crank
5 Start pause
6 Cool down 000s (000s: the remaining time is displayed)
7 Engine stop!
8 Preglow
9 Purging operation
10 Initial state
11 Auxiliary prerun
12 Auxiliary postrun
13 Mains settling 000s (000s: the remaining time is displayed)
14 Lambda initial state
15 Sprinkler coasting
16 Ignition
17 --Internal--
18 --Internal--
19 --Internal--
20 --Internal--
21 --Internal--
22 --Internal--
23 --Internal--
24 Phase rotation incorrect!
25 Start without closing GCB and simultaneous emergency power
26 Start without closing GCB
27 Sprinkler operation (critical mode) and simultaneous emergency power
28 Sprinkler operation (critical mode)
29 Emergency power
30 TEST
31 Load TEST
32 --Internal--
33 --Internal--
34 --Internal--
35 --Internal--
36 --Internal--
37 --Internal--
38 --Internal--
39 --Internal--
40 --Internal--
41 --Internal--
42 --Internal--
43 --Internal--
44 --Internal--
45 --Internal--
46 --Internal--
47 Power reduction
...
255 No message on the display (basic screen)
