Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
© Woodward Page 171/190
No. Content (words) Unit Comment
59
External alarm Bit 15 = 1 \
Bit 14 = 1 /
Terminal 69
Bit 13 = 1 \
Bit 12 = 1 /
Terminal 70
Bit 11 = 1 \
Bit 10 = 1 /
Terminal 71
Bit 9 = 1 \
Bit 8 = 1 /
Terminal 72
Bit 7 = 1 \
Bit 6 = 1 /
Terminal 73
Bit 5 = 1 \
Bit 4 = 1 /
Terminal 74
Bit 3 = 1 \
Bit 2 = 1 /
Internal
Bit 1 = 1 \
Bit 0 = 1 /
Internal
60
Internal fault 7 Bit 15 = 1 Internal
Bit 14 = 1 Internal
Bit 13 = 1 Internal
Bit 12 = 1 Internal
Bit 11 = 1 Internal
Bit 10 = 1 Internal
Bit 9 = 1 Internal
Bit 8 = 1 Internal
Bit 7 = 1 Internal
Bit 6 = 1 Internal
Bit 5 = 1 Internal
Bit 4 = 1 Internal
Bit 3 = 1 Internal
Bit 2 = 1 Internal
Bit 1 = 1 Internal
Bit 0 = 1 Internal
61
Analog input 1 (terminals 93 to 95) The measured value is transmitted.
62
Analog input 2 (terminals 96 to 98) The measured value is transmitted.
63
Analog input 3 (terminals 99 to 101) The measured value is transmitted.
64
Analog input 4 (terminals 102 to 105) The measured value is transmitted.
65
Reserve
Internal
66
Reserve Internal
67
Reserve Internal
68
Reserve Internal
69
The currently active display A number is transmitted; please consult the following table for the
meaning of this number.
The next genset is addressed with the number 70
Word 0 CAN-Bus (CAL)-Bus (Watchdog)
Word 1 generator voltage V
12
Word 2 etc.
H.B. High Byte L.B. Low Byte
H.W. High Word L.W. Low Word
UGNEXPO Exponent Generator voltage USSEXPO Exponent Busbar voltage
UGNEXPO Exponent Generator voltage USSEXPO Exponent Busbar voltage
IGNEXPO Exponent Generator current UNTEXPO Exponent Mains voltage
PGNEXPO Exponent Generator power PNTEXPO Exponent Mains power
PGNWD Step conversion factor Æ kW
