Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
Page 170/190 © Woodward
No. Content (words) Unit Comment
56
Internal fault 4 Bit 15 = 1 \
Bit 14 = 1 /
Analog input 1 - level 1
Bit 13 = 1 \
Bit 12 = 1 /
Analog input 1 - level 2
Bit 11 = 1 \
Bit 10 = 1 /
Analog input 2 - level 1
Bit 9 = 1 \
Bit 8 = 1 /
Analog input 2 - level 2
Bit 7 = 1 \
Bit 6 = 1 /
Analog input 3 - level 1
Bit 5 = 1 \
Bit 4 = 1 /
Analog input 3 - level 2
Bit 3 = 1 \
Bit 2 = 1 /
Analog input 4 - level 1
Bit 1 = 1 \
Bit 0 = 1 /
Analog input 4 - level 2
57
Internal fault 5 Bit 15 = 1 \
Bit 14 = 1 /
Internal
Bit 13 = 1 \
Bit 12 = 1 /
Internal
Bit 11 = 1 \
Bit 10 = 1 /
Internal
Bit 9 = 1 \
Bit 8 = 1 /
Internal
Bit 7 = 1 \
Bit 6 = 1 /
Internal
Bit 5 = 1 \
Bit 4 = 1 /
Internal
Bit 3 = 1 \
Bit 2 = 1 /
Internal
Bit 1 = 1 \
Bit 0 = 1 /
Internal
58
External faults terminals 61 to 68 Bit 15 = 1 \
Bit 14 = 1 /
Terminal 61
Bit 13 = 1 \
Bit 12 = 1 /
Terminal 62
Bit 11 = 1 \
Bit 10 = 1 /
Terminal 63
Bit 9 = 1 \
Bit 8 = 1 /
Terminal 64
Bit 7 = 1 \
Bit 6 = 1 /
Terminal 65
Bit 5 = 1 \
Bit 4 = 1 /
Terminal 66
Bit 3 = 1 \
Bit 2 = 1 /
Terminal 67
Bit 1 = 1 \
Bit 0 = 1 /
Terminal 68
